| Ford 2.3 / 2.5L OHC |
| Oil Pan Zipper Kit E-L gasket |
|
|
| Remove oil pan. |
|
| Clean off oil pan gasket surface on block. |
|
| Locate a blind pan bolt hole. * |
|
| Use blue Loctite on the threads going into
the block. |
|
| Install a stud using a 3mm allen wrench. |
|
| Run it down till it bottoms in the hole. |
|
| Use this to set the depth of the other studs. |
|
| Install other studs with blue Loctite. |
|
| Wipe off any excess Loctite. |
|
| Install the stepped studs next to the
crankshaft. |
|
|
|
| Oil Pan installation; |
| Rubber gasket; |
|
| Clean oil pan gasket surface. |
|
| Install
gasket and oil pan. |
|
| Install nuts (NO Loctite) and torque to 4 - 6
Lb/Ft |
|
|
|
| Cork gasket; |
|
| Clean oil pan gasket surface. |
|
| Install gasket onto block. |
|
| Install oil
pan. |
|
| Install nuts (NO Loctite) and torque to 4 - 6
Lb/Ft |
|
|
|
| * Some bolt holes are not drilled and tapped
all the way thru. |
|
|
|
